Cc MHC 800

800×800 mm Square

Manhole Cover

D400 / C250

Type: Heavy and Medium Load Type
Class : D400 / C250
Load Capacity : 400 Kn (40 Ton) / 250 Kn ( 25 Ton )

The non-hinged square frame composite manhole cover, which has a load-bearing capacity of 40 tons (400 kN) for heavy loads, is made from materials resistant to heavy loads. It weighs 65 kilograms. Based on the measurements, the inner dimensions of the bottom part of the manhole cover have a diameter of Ø 600 mm. When considering the outer dimensions, it is 800 x 800 mm. The cover itself has a diameter of Ø 697 mm. The thickness of the cover is 50 mm, and the bottom seating part is 82 mm thick.

Cover diameter: Ø 697 mm
Outer dimensions: 800×800 mm
Class: D400 / C250
Load-bearing capacity: 400 kN (40 Ton) / 250 kN (25 Ton)

Features

It has a non-hinged square frame system and 1 manual locking system.
There is 1 metal handle on the cover.
Rubber-based seals are used on the cover seating surfaces.
Manufactured in compliance with TS 1478 EN124 standards.

Areas of Use

Suitable for all types of road vehicles, including road freight vehicles (including pedestrian streets), safety lanes, and parking areas.

Advantages

Lighter than metal.
Requires no maintenance and has no risk of theft.
Resistant to corrosion and does not rust.
Easy to transport and assemble.
Color and logo options are available.
